LiFePO4
FLA48500TG2
25kWh | 51.2V | LV
What Sets It Apart.
High-capacity, safe, and intelligently managed home energy storage.
25kWh Nominal Energy
Single-unit energy for reliable backup.
250A Charge/Discharge Current
High continuous current for demanding loads.
≥95% Depth of Discharge
More usable energy from every charge.
Built-in Smart BMS
Independent BMS with multiple protection functions.
LiFePO4 Battery Chemistry
Higher safety and longer cycle life.
Up to 15 Units in Parallel
Scalable to 375kWh for long-term storage needs.
Built-in WiFi/Bluetooth
Remote monitoring of battery pack data.
Aerosol Fire Extinguishing System
Equipped for enhanced fire safety.
External Replaceable Fuse
Easy fuse replacement without opening the unit.
Specifications
Detail Specifications of FLA48500TG2
| Model | FLA48500TG2 |
|---|---|
| Battery Type | LiFePO4 |
| Nominal Energy | 25kWh |
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Max. Continuous Charge/Discharge Current | 250A |
| Max. Charge/Discharge Power | 12500W |
| Depth of Discharge (DOD) | ≥95% |
| Cycle Life | ≥6000 Cycles (25°C±2°C, 0.5C/0.5C, 90% DOD, 70% EOL) |
Flexible Capacity and System Expansion
The FLA48500TG2 supports parallel connection of up to 15 units for high-capacity expansion.
25kWh
Rated energy of a single unit.
375kWh
Maximum system energy with up to 15 units in parallel.
Overview:
FLA48500TG2
FLA48500TG2 is equipped with a lithium iron phosphate battery designed for household use. Developed based on customer needs and market demands, this advanced battery storage solution provides high-quality, reliable power for various devices. The product features a long lifespan, suitability for high-temperature environments, and a compact design that requires minimal installation space.
FLA48500TG2 features a battery management system independently developed by our team. When connected to a grid or photovoltaic system as the power source, the product can store energy by charging the battery. In the event of a power outage from the grid or photovoltaic system, the product independently supplies electricity to household loads. Additionally, multiple units can be connected in parallel to form a high-capacity, multi-module system, meeting long-term energy storage requirements.
Overview
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Multiple Bracket Options
Adapt to different installation scenarios with flexible configuration for FLA48500TG2
9-Layer Bracket
Medium capacity configuration with high cost performance
13-Layer Bracket
Medium capacity configuration with high cost performance
16-Layer Bracket
Medium capacity configuration with high cost performance
Application Scenarios
FLA48500TG2 delivers scalable, reliable energy storage for residential, commercial, and institutional applications.
Factory
Store
Warehouse
Villa
School
Resident
Hospital
Download
Click to Download
[Certificate for Safe Transport of Goods by Road] FLS2F8803YL501（FLA48500TG2）.pdf
1.72 MB
[Certificate for Safe Transport of Goods by Sea] FLS2F8803YM701 （FLA48500TG2）.pdf
1.74 MB
[GHS Label Design Report] FLS2F8803P01（FLA48500TG2）.pdf
0.66 MB
[Hazard and Classification Identification] FLS2F8803DI01（FLA48500TG2）.pdf
0.78 MB
[MSDS] FLS2F8803SDS01（FLA48500TG2）.pdf
0.92 MB
[UN38.3 TEST REPORT] FLS2F8803U01（FLA48500TG2）.pdf
1.05 MB
[UN38.3 TEST REPORT] FLS2F9801U01_2P4S FLA48500TG2.pdf
2.23 MB
[UN38.3 TEST Summary] FLS2F8803G01（FLA48500TG2）.pdf
0.27 MB
[Verification of Overcharge-Short-Overdischarge Protection] FLS2F8803W01（FLA48500TG2）.pdf
0.84 MB
